EFF I C I ENCY
OPERaB I L I TY
SaFE TY
PRODUC T I V I TY
Simple controls for easyoperation
The controls on 8FBRE reach forklifts are as you would
expect – simple and logical, with fingertip control levers for all
fork movements, and effortless electronic steering for precise
driving. The steering system offers 360° flexibility, although
conventional 180° steering is available as an option. PIN-code
start-up ensures only authorised drivers can operate the truck.
• Single levers for hydraulic functions
• 3-4 hydraulic functions
• Simple, logic layout
• Excellent control
• Support for the wrist
• For any conceivable purpose
• Easy to learn and use
• Safe and productive
• Ergonomic, comfortable
Easy access for simple servicing
Designed with few
components the
8FBRE allows
easy access to the
forklifts electronic
components making
maintenance and
service easy to
perform. The
battery charging
outlet connector
is easy to access.
The all newToyota 8FBRE reach forklifts -
Easy-to-use and fullyoptimised for efficiency.
1
2
Simple 360º steering
The 8FBRE offers full 360º steering for ergonomic and efficient
operation. Other benefits include:
• Short learning process
• Easy to find shortest turning radius
• Faster working cycles
• 180º steering as an alternative
Narrowupper chassis and
drive-in racking
(optional)
The 8FBRE offers a narrow frame and drive-in racking as
an optional feature, providing increased space utilisation to
optimise pallet storage capacity.
Fits typical
drive-in racking
8FBRE-series
A 1420mm
B 1520mm
3
9
10
4
5
910mm
A B
6
7
8
Programmableperformance
The 8FBRE is completely programmable for optimum
performance and safety with a complete array of
programmable functions such as:
• Steering sensitivity
• Top speed
• Acceleration
• Auto (motor) brake
• Timed shutdown
Optimumvisibility
The 8FBRE is available with two kinds of masts. The
Duplex tele, 2-stage mast (V) with panoramic view and the
Triplex free lift, 3-stage mast (FSV) with clear view.
automatic parkingbrake
• Applies automatically when leaving
the 8FBRE
• Releases when choosing direction
+ pressing the accelerator
• Machine is always safely parked
when the driver leaves the forklift
Triplex
hilo mast
Duplex
Tele mast
P
Ergonomic drivers compartment
All key driver compartment parts are adjustable to make
the 8FBRE suitable for all shapes and sizes of drivers,
enhancing both safety as well as driver comfort.
adjustablefloor
To increase driver
comfort, the floor is
adjustable in three
different heights;
450, 495 & 540mm,
seat to floor.
adjustable steering console
• Easy fold up
• Fits every driver
• Comfortable position means less
operator fatigue and higher productivity
• Easy entry and exit from the cabin
